Fix It Sticks tools are regarded as the top choice for demanding users who require portable yet robust tools while on the go. Our tools are used by competitive shooters and cyclists, military operators and tool enthusiasts all over the world. Used properly, your Fix It Sticks tools will provide years, if not a lifetime, of shop tool experiences in the field.
Hex bits are considered consumable, and prone to wear. BE SURE TO STAY WITHIN OPERATIONAL LIMITS WHEN USING, and please note we cannot be responsible for hex bit breakage while attempting to remove a previously over-torqued fastener.
Hex Bit Operation Limit Chart
SAE Allen Hex
.050"
Working Limit: 6 in-lbs
Failure Limit: 7 in-lbs
1/16"
Working Limit: 10 in-lbs
Failure Limit: 13 in-lbs
5/64"
Working Limit: 20 in-lbs
Failure Limit: 25 in-lbs
3/32"
Working Limit: 40 in-lbs
Failure Limit: 45 in-lbs
7/64"
Working Limit: 60 in-lbs
Failure Limit: 70 in-lbs
1/8"
Working Limit: 88 in-lbs
Failure Limit: 100 in-lbs
9/64"
Working Limit: 125 in-lbs
Failure Limit: 150 in-lbs
5/32"
Working Limit: 175 in-lbs
Failure Limit: 190 in-lbs
3/16"
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
7/32"
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
1/4"
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
5/16"
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
Metric HEX
1.5mm
Working Limit: 6 in-lbs
Failure Limit: 7 in-lbs
2mm
Working Limit:20 in-lbs
Failure Limit: 25 in-lbs
2.5mm
Working Limit: 40 in-lbs
Failure Limit: 45 in-lbs
3mm
Working Limit: 60 in-lbs
Failure Limit: 70 in-lbs
4mm
Working Limit:130 in-lbs
Failure Limit: 150 in-lbs
4.5mm
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
5mm
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
5.5mm
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
6mm
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
7mm
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
8mm
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
SAE Slotted
3/32
Working Limit: 12 in-lbs
Failure Limit: 15 in-lbs
3/16
Working Limit: 18 in-lbs
Failure Limit: 20 in-lbs
1/4
Working Limit: 65 in-lbs
Failure Limit: 75 in-lbs
Phillips
P0
Working Limit: 12 in-lbs
Failure Limit: 15 in-lbs
P1
Working Limit: 25 in-lbs
Failure Limit: 30 in-lbs
P2
Working Limit: 65 in-lbs
Failure Limit: 70 in-lbs
P3
Working Limit: 160 in-lbs
Failure Limit: 200 in-lbs
P4
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
TORX
T6
Working Limit: 6 in-lbs
Failure Limit: 7 in-lbs
T8
Working Limit: 15 in-lbs
Failure Limit: 18 in-lbs
T10
Working Limit: 25 in-lbs
Failure Limit: 45 in-lbs
T15
Working Limit: 40 in-lbs
Failure Limit: 65 in-lbs
T20
Working Limit: 60 in-lbs
Failure Limit: 110 in-lbs
T25
Working Limit: 85 in-lbs
Failure Limit: 180 in-lbs
T27
Working Limit: 90 in-lbs
Failure Limit: 180 in-lbs
T30
Working Limit: 185 in-lbs
Failure Limit: 200 in-lbs
